如下为我司爱泽工业IZE_Industries本月到货ZEVATRON相关产品，欢迎致电索取样本资料和产品信息。


ZEVATRON电烙铁P30 LKP030450A00


ZEVATRON电烙铁H20 LKH020280A00


ZEVATRON烙铁头ZP309 LS030930190Z


ZEVATRON烙铁头ZP199 LS199195170Z

ZEVATRON电烙铁介绍
ZEVATRON 生产连续使用的烙铁。烙铁头温度高、有效的储热功能可防止过多的热量损失，并且快速重新加热可确保高效工作。

所有烙铁均提供 230 伏电压，配有 3 线电源线和模制 Schuko 插头。绝缘安全烙铁配有 2 线电源线和异型插头或欧式插头。可达到的*高烙铁头温度各不相同。它们本质上取决于给定的电源电压、所用焊头的几何形状和涂层以及加热头中焊头的夹紧长度。

ZEVATRON 烙铁有直形 (GR) 和角形 (P) 以及功率从 60W 到 450W 的锤形烙铁 (H) 。

标准焊头通常有多种形状可供选择。对于使用无铅合金，推荐使用“ZP”优质焊嘴。

ZEVATRON manufactures soldering irons for professional continuous use. High soldering tip temperatures, an effective heat storage against excessive heat loss and rapid reheating ensure efficient work.

All soldering irons are supplied for 230 volts, with a 3-wire power cable and a molded Schuko plug. The insulated safety soldering irons have a 2-wire power cable and contour or Euro plug. The maximum achievable soldering tip temperatures vary. They essentially depend on the given mains voltage, the geometry and the coating of the soldering tip used as well as on the clamping length of the soldering tips in the heating head.

The ZEVATRON soldering irons are available in straight and angled shapes, as well as hammer-shaped ones with powers from 60W to 450W.

Standard soldering tips are usually available from stock in many shapes. For working with lead-free alloys, recommend “ZP” quality soldering tips.

ZEVATRON电烙铁P30 LKP030450A00介绍
功率（W）：450
*高温度（℃）：约500
直径（mm）：30
净重（g）：1750

Power (W): 450
max.temperature (°C): approx. 500
Diameter (mm): 30
Net weight in grams: 1750

ZEVATRON电烙铁H20 LKH020280A00介绍
功率（W）：280
温度上限（°C）：约450
直径（mm）：19.5
净重（g）：906

Power (W): 280
max.temperature (°C): approx. 450
Diameter (mm): 19.5
Net weight in grams: 906

ZEVATRON电烙铁头介绍
Zevatron 永久烙铁头也由纯电解铜制成。通过尖端上均匀且有弹性的铁涂层，可以保护永久性焊接尖端免受焊料侵蚀和助焊剂腐蚀。烙铁头的其余部分均镀铬。焊接翅片也经过预镀锡。由于这种表面处理，永久烙铁头的使用寿命延长了 10 至 20 倍，这意味着即使长时间使用烙铁头也不需要返工。

Zevatron permanent soldering tips are also made from pure electrolytic copper. The permanent soldering tips are protected against erosion by solder and corrosion by fluxes by a homogeneous and elastic iron coating on the tip. The rest of the soldering tip is chrome plated. The soldering fin is also pre-tinned. Thanks to this surface treatment, the permanent soldering tips have a service life that is 10 to 20 times longer, meaning the tip does not need to be reworked even after long periods of use.

ZEVATRON烙铁头ZP199 LS199195170Z介绍
兼容 P20、H20 烙铁头
直径19x160mm

Compatible with Soldering tip for P20, H20
Diameter 19x160mm

ZEVATRON烙铁头ZP309 LS030930190Z介绍
兼容 P30、H30 烙铁头
直径30x190mm

Compatible with Soldering tip for P30, H30
Diameter 30x190mm

ZEVATRON电烙铁及烙铁头常用型号：
ZEVATRON GR6 LKGR06060A00
ZEVATRON GR9H LKGR90100AOH
ZEVATRON P6 LKP006070A00
ZEVATRON P9 LKP009110A00
ZEVATRON P10 LKP010130A00
ZEVATRON P15 LKP015180A00
ZEVATRON P20 LKP020280A00
ZEVATRON P30 LKP030450A00
ZEVATRON H9 LKH009110A00
ZEVATRON H10 LKH010140A00
ZEVATRON H15 LKH015180A00
ZEVATRON H20 LKH020280A00
ZEVATRON H30 LKH030450A00
ZEVATRON ZP 61K LS061K06090Z
ZEVATRON ZP 61 L LS061L06110Z
ZEVATRON ZP 63K LS063K06090Z
ZEVATRON ZP 63 L LS063L06110Z
ZEVATRON ZP 64K LS064K06090Z
ZEVATRON ZP 64 L LS064L06110Z
ZEVATRON ZP 65K LS065K06090Z
ZEVATRON ZP 65 L LS065L06110Z
ZEVATRON ZP 67K LS067K06090Z
ZEVATRON ZP 67 L LS067L06110Z
ZEVATRON ZP 71K LS071K75100Z
ZEVATRON ZP 71 L LS071L75125Z
ZEVATRON ZP 74K LS074K75100Z
ZEVATRON ZP 74 L LS074L75125Z
ZEVATRON ZP 75K LS075K75100Z
ZEVATRON ZP 75 L LS075L75125Z
ZEVATRON ZP 77K LS077K75100Z
ZEVATRON ZP 77 L LS077L75125Z
ZEVATRON ZP 91K LS091K95130Z
ZEVATRON ZP 91 L LS091L95140Z
ZEVATRON ZP 91 LW LS91LW95130Z
ZEVATRON ZP 93K LS093K95130Z
ZEVATRON ZP 93 L LS093L95140Z
ZEVATRON ZP 97K LS097K95130Z
ZEVATRON ZP 97 L LS097L95140Z
ZEVATRON ZP 151 LS015115A04Z
ZEVATRON ZP 156 LS015615135Z
ZEVATRON ZP 159 LS015915130Z
ZEVATRON ZP 199 LS199195170Z
ZEVATRON ZP 309 LS030930190Z

如果您需要完整的ZEVATRON的相关技术咨询，请随时致电爱泽工业，或者访问网站,我们将尽全力解决您的问题。
