Technical data Type 4551A... KiTorq Rotor, Type 454xA... KiTorq Stator
Rated torque Mnom N·m 50 / 100 / 200 / 500 / 1 000 / 2 000 / 3 000 / 5 000
Maximum torque 2 × rated torque
Alternating torque 1 × rated torque
Accuracy class 0,05
Linearity error
including hysteresis
% FSO 0,03
Output signal
(rated value)
Mnom VDC
kHz
10 or
10 ±5, 100 ±40, 240 ±120 and RS-232C / USB
Output signal
(digital)
PROFINET, PROFIBUS, CANopen, EtherCAT, EtherNet/IP
Speed & angle
measurement
pulses/rev. up to 8 192 pulses + Z-pulse
Rated speed 1/min ≤20 000 (Depending on measuring range)
Case material hard-anodized aluminum
Dimensions L
D
H
R
W
mm
mm
mm
mm
mm
44
112 ... 253,5
189,5 ... 331
34 ... 64
210
Operating temperature range °C 10 ... 60







定子- 扭矩传感器

瑞士奇石乐扭矩传感器   KISTLER扭矩传感器
KiTorq扭矩测量法兰

型号 4550A

KiTorqu系统是扭矩测量法兰系统，由455XA型扭矩测量单元KiTorq转子和454XA型扭矩评估单元KiTorq定子组成。KiTorq系统的转子和定子具有相同的转速选项，可组合使用。
