韩国KODONXG系列超声波发生器

价格电议,您可以向供应商询价得到该产品价格

上海

上海君翼仪器设备有限公司

13年

指数：270

工商已认证

店铺推荐

图文详情
产品参数

韩国KODO NXG-SA超声波发生器特点和参数：
•Output Control - Output level can be controlled from 10 to 99%.
•SWEEP Function - Built in Sweep function has a great affect in deaeration and decreasing stain spots (Dead Zone).
•Remote Function - Remote control function using exterior point of contract.
•FND Function - One can easily identify frequency, power, time, and temperature through FND.
•Other Functions - Alarm Function, 4~20mA communication function.
*输出控制-输出电平可控制在10%~99%之间。
·*SWEEP功能-对除气和减少污点(死区)有良好的效果。
·远程功能-使用外部契约点的遥控功能。
·fnd功能-通过fnd可以方便地识别频率、功率、时间和温度。
·其他功能-报警功能、4~20 ma通信功能。

超声波发生器型号	NXG-SA600 / SA900 / SA1200 / SA1500 / SA1800
超声波频率	28Khz / 40Khz
超声波输出功率	600W / 900W / 1200W / 1500W / 1800W
超声波换能器	B.L.T Transducer
SWEEP 功能	O
控制方法	Analog Type模拟量
尺寸(mm)	300x400x120
电源	AC220V/60Hz
重量	约12Kg

韩国KODO NXG-HD高频超声波发生器特点和参数：
•Generator for High-frequency - NXG-HD series is designed for high-frequency from 68Khz to
168Khz.
•Easy of Use - Users can easily control the operation using control panel.
•Self Diagnosis Function - Users can easily figure out the cause of malfunction due to self
diagnosis function.
•DATA Check - One can easily check operation frequency, power, and internal
temperature level without separate measuring instrument.
•RS-485 Communication - Though the RS-485 communication, users can monitor and control
operation on PLC.
•Alarm Function - It alerts the users if there is any problem.

高频超声波发生器型号	NXG-HD-68K/75K/100K/132K/168K
超声波频率	68Khz/75Khz/100Khz/132Khz/168Khz
超声波输出功率	600W / 900W / 1200W
超声波换能器	B.L.T Transducer
振动方法	PLL
尺寸(mm)	310x440x130
输入电压	AC220V/60Hz
输入电流	6A(at 1200W of output)
重量	约12Kg

韩国KODO NXG-HSS高速切换三频率发生器特点和参数：
High-speed switching 3-Frequency Generator NXG-HSS
1) By switching the position of the standing wave for three different frequencies at a high speed, it
provides a cleaning power of each frequency at the same time.
2) Because the positions of the standing wave of each frequeny is different.
A.To prevent stains caused by standing waves.
B.It provides precise cleaning, and can also reduce damage to the cleaning tank.
3) The burst wave generated by high-speed switching method creates a number of high-order vibration
to the cleaning of the glass capillary tube and precision parts.
4) Ultrasound of 100Khz is a degassing effect, it is possible to prevent the attenuation of ultrasonic
cleaning power to keep up to near the top of the wash tank.
5) The pumping effect caused by high speed switching(mSec) is effecting washed complex fine holes.
6) The life time of Tank and Transducers increases.

超声波发生器型号	NXG-HSS
超声波发生器方法	Oscillation Mode Choice F1-F2, F1-F3, F2-F3 2 frequency Switching / F1-F2-F3 3 frequency Switching
切换周期	1~10ms Selectable
超声波频率	28K/45K/100Khz
超声波输出功率	600W / 600W / 300W
超声波换能器	B.L.T Transducer for Multi Transducer
输入功率	Single AC200V ~ AC220V / 60Hz, 4A Max
显示	Character LCD(2 * 20) & LED
输出功率	50% ~ 100%
计时器	1sec ~ 99min 59sec
环境	Temperature:0~40℃, Humidity 0~80%
尺寸(mm)	310x440x130
重量	约12Kg

韩国KODO NXG-MD低输出超声波发生器特点和参数：
High-speed switching 3-Frequency Generator NXG-HSS
1) By switching the position of the standing wave for three different frequencies at a high speed, it
provides a cleaning power of each frequency at the same time.
2) Because the positions of the standing wave of each frequeny is different.
A.To prevent stains caused by standing waves.
B.It provides precise cleaning, and can also reduce damage to the cleaning tank.
3) The burst wave generated by high-speed switching method creates a number of high-order vibration
to the cleaning of the glass capillary tube and precision parts.
4) Ultrasound of 100Khz is a degassing effect, it is possible to prevent the attenuation of ultrasonic
cleaning power to keep up to near the top of the wash tank.
5) The pumping effect caused by high speed switching(mSec) is effecting washed complex fine holes.
6) The life time of Tank and Transducers increases.

超声波发生器型号	NXG-HSS
超声波发生器方法	Oscillation Mode Choice F1-F2, F1-F3, F2-F3 2 frequency Switching / F1-F2-F3 3 frequency Switching
切换周期	1~10ms Selectable
超声波频率	28K/45K/100Khz
超声波输出功率	600W / 600W / 300W
超声波换能器	B.L.T Transducer for Multi Transducer
输入功率	Single AC200V ~ AC220V / 60Hz, 4A Max
显示	Character LCD(2 * 20) & LED
输出功率	50% ~ 100%
计时器	1sec ~ 99min 59sec
环境	Temperature:0~40℃, Humidity 0~80%
尺寸(mm)	310x440x130
重量	约12Kg

加工定制：	否
品牌：	韩国KODO
类型：	一体式
适用领域：	电子行业
用途：	工业用
槽数：	4
型号：	NXG系列
超声清洗频率：	28~120khz
