￥1850.00

北京

北京星研控科技有限责任公司

免费会员

已传执照

相似推荐

图文详情
产品参数

【1U Single】P1H-5400V

400W

Server ,Workstation ,Storage System ,IPC

225x100x40.5(mm)
8.86x3.94x1.59(inch)
VOLTAGE: 90 ~ 264 VAC FULL RANGE
FREQUENCY: 47~63 HZ
INPUT CURRENT:6A ( RMS ) FOR 115VAC /
3A ( RMS ) FOR 230VAC
INRUSH CURRENT: 20A MAX. FOR 115 VAC /
40A MAX. FOR 230 VAC

Output VoltageTD	Output Current Min.	Output Current Max.	Regulation Load	Regulation Line	Output Ripple & Noise Max.[P-P]
+5V	0.5	22	±5%	±1%	50mV
+12V	2	32	±5%	±1%	120mV
-12V	0	0.8	±5%	±1%	120mV
+3.3V	0.5	22	±5%	±1%	50mV
+5VSB	0.1	3.5	±5%	±1%	50mV

* TEMPERATURE RANGE: OPERATING 0℃ --- 50℃, STORAGE –20℃ --- 80℃
* HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & NORMAL INPUT VOLTAGE
* EFFICIENCY: 80% TYPICAL AT 115V, FULL LOAD
* POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
* OVER POWER PROTECTION
* OVER VOLTAGE PROTECTION
* OVER CURRENT PROTECTION
* SHORT CIRCUIT PROTECTION
* EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
* SAFETY: TO MEET UL, CUL, TUV, CCC * 3.3V / 5V REMOTE SENSING
* COOLING: ONE 40mm DC FANS
* ACTIVE POWER FACTOR CORRECTION MEET IEC-1000-3-2 CLASS D

*THE POWER-SUPPLY IS FOR CHASSIS-ASSEMBLY ONLY AND IS NOT ALLOWED TO BE OPERATED AS STAND-ALONE COMPONENT. FINAL ASSEMBLY HAS TO COMPLY WITH CORRESPONDING EMC- AND SAFETY-REGULATIONS.

品牌：	新巨电源
类型：	通信电源
输入电压：	220 V
输出功率：	550 W
型号：	P1H-5400V
