自来水管道防水切管机 液压切割机 自动爬行设备先机XJQG-1
9494.00
天津北辰区
天津市先锋管道工程机械有限公司
免费会员 | 已传执照
相似推荐
  • 图文详情
  • 产品参数














序号 型号 TYPE 额定压力*   Rated pressure 流量*    flow rate 排量*displacement 输出扭矩*   output torque 铣刀转速 (r/ Min)* milling cutter speed

    *大切割深度(mm)

  Maximum cutting depth

不锈钢合金管Stainless steel alloy pipe 铸铁管  cast iron pipe 钢管 steel pipe PE管  pe pipeline
 1  XJQG-1  10Mpa 35L/min  160ml/r  191N.m  125   26mm 32mm 30mm  35mm
 2  XJQG-3  10Mpa 35L/min  160ml/r  191N.m   90   26mm 32mm 30mm  35mm
 3  XJQG-5  10Mpa 35L/min  160ml/r  191N.m   85   35mm 45mm 40m  60mm



            切割速度 (mm/Min)

                   Cutting speed

   切割管径范围

 Cutting pipe diameter range

  不锈钢合金管

 Stainless steel alloy   pipe

 铸铁管

 cast iron   pipe

 钢管

 steel pipe

  PE管

 pe pipeline

      70    90   80    95    DN200-4000mm
      70    90   80    95    DN200-600mm
      60    80   65    95    DN200-1000mm









1.可以对管道同时进行切割和坡口作业,以提高管道焊接速度。

Cutting and beveling operatis can be performed simultaneously on pipelines to improve welding speed.




2.管道切割作业时,切管机能够穿越30mm距离空隙。

During pipeline cutting operations, the pipe cutting machine is able to pass through a gap of 30mm distance.





3.切管机应当具有行进暂停功能,实现单点切透管道壁,以便于对管道内的气体 进行测量以及管道材质的取样。

The pipe cutting machine should have a driving pause function to achieve single point cutting through the pipeline wall, in order to measure the gas inside the pipe line and sample the pipeline material.





4.切管机应当只需更换链条实现从DN200至4000管径大范围变化的切割作业, 而不需要再增购其它设备,实现真正的一机专切。

The pipe cutting machine should only replace the chain to achieve a wide range of cutting operations from DN200 to 4000 pipe diameters, without the need to purchase other equipment, achieving true one machine dedicated cutting.





5.切管机应当按照ISO9001标准及企业生产规范限定其安全切割速度,以保证 其在危险环境下安全进行低温、防爆、无火花作业。

The pipe cutting machine should limit its safe cutting speed in accordance with ISO9001 standards and enterprise production specifications to ensure safe low-tem perature, explosion-proof, and spark free operations in hazardous environments.





6.配套使用的液压泵站应当提供稳定的工作压力和流量,以满足切管机在管道 切割作业时所需的动力。

The hydraulic pump station used in conjunction should provide stable working pressure and flow rate to meet the power requirements of the pipe cutting machine during pipeline cutting operations.





品牌:先机
型号:XJQG-1
加工定制:
切割能力:
空载转速:100 bpm
额定转速:100 rpm
电源类型:无电 液压
最大锯切深度:32 mm
